5th generation Intel Xeon Processors

March 25, 2024
Share Post Pin E-mail

5th generation Intel Xeon Processors

Advanced grows on workload performance

Standard features

 Processor Suffix Description Offering
H Database and Analytics Highest core counts. Database and Analytics usages benefit from Intel Data Streaming Accelerator (DSA)  and Intel In-Memory Accelerator Analytics (IAA)
M Media Transcode Optimized for Intel Advanced Vector Extensions (AVX) frequencies to deliver better performance/watt for  Media, AI, and HPC workloads.
N Network/5G/Edge (High Throughput / Low Latency) Designed for Network Function Visualization and networking workloads, such as: L3 forwarding, 5G User Plane Function, Open vSwitch Data Plane Development Kit, Vector Packet Processing FIB router, VPP IPsec, web server/NGINX, vEPC, vBNG, and vCMTS.
S Storage and HCI Optimized for Storage UMA use cases with increased UPI Bandwidth for vs Mainline SKUs.
P Cloud - IAAS Designed for cloud IaaS environments to deliver higher frequencies at constrained TDPs.
Q Liquid Cooling Liquid cooled processors with higher frequency and performance at same TDP.
U Single Socket Optimized Optimized for targeted platforms adequately served by the cores, memory bandwidth and IO capacity

available from a single processor
V Cloud - SAAS Optimized for orchestration efficiency that delivers higher core counts and VMs per rack.
Y Intel SST-PP (Speed Select Technology - Performance Profile) Intel® SST-PP increases base frequency when fewer cores are enabled. Allows greater flexibility, deployment options and platform longevity.



5th  Generation Intel® Xeon® Scalable Processor Family (Platinum)

 Intel® Xeon® Models Frequency Cores Power DDR5 SGX Enclave size
Platinum 8593Q Processor 2.2 GHz 64 385W 5600 MT/s 512 GB
Platinum 8592+ Processor 1.9 GHz 64 350W 5600 MT/s 512 GB
Platinum 8592V Processor 2.0 GHz 64 330W 4800 MT/s 512 GB
Platinum 8581V1 Processor 2.0 GHz 60 270W 4800 MT/s 512 GB
Platinum 8580 Processor 2.0 GHz 60 350W 5600 MT/s 512 GB
Platinum 8570 Processor 2.1 GHz 56 350W 5600 MT/s 512 GB
Platinum 8568Y Processor 2.3 GHz 48 350W 5600 MT/s 512 GB
Platinum 8562Y+ Processor 2.8 GHz 32 300W 5600 MT/s 512 GB
Platinum 8558P Processor 2.7 GHz 48 350W 5600 MT/s 512 GB
Platinum 8558 Processor 2.1 GHz 48 330W 5200 MT/s 512 GB
Platinum 8558U1 Processor 2.0 GHz 48 300W 4800 MT/s 512 GB





5th Generation Intel® Xeon® Scalable Processor Family (Gold 6)

 Intel® Xeon® Models Frequency Cores Power DDR5 SGX Enclave size
Gold 6558Q Processor 3.2 GHz 32 350W 5200 MT/s 128 GB
Gold 6554S Processor 2.2 GHz 36 270W 5200 MT/s 128 GB
Gold 6548N Processor 2.8 GHz 32 300W 5200 MT/s 128 GB
Gold 6548Y+ Processor 2.5 GHz 32 250W 5200 MT/s 128 GB
Gold 6544Y Processor 3.6 GHz 16 270W 5200 MT/s 128 GB
Gold 6542Y Processor 2.9 GHz 24 250W 5200 MT/s 128 GB
Gold 6538N Processor 2.1 GHz 32 205W 5200 MT/s 128 GB
Gold 6538Y+ Processor 2.2 GHz 32 225W 5200 MT/s 128 GB
Gold 6534 Processor 3.9 GHz 8 195W 4800 MT/s 128 GB
Gold 6530 Processor 2.1 GHz 32 270W 4800 MT/s 128 GB
Gold 6526Y Processor 2.8 GHz 16 195W 5200 MT/s 128 GB





5th Generation Intel® Xeon® Scalable Processor Family (Gold 5)

 Intel® Xeon® Models Frequency Cores Power DDR5 SGX Enclave size
Gold 5520+ Processor 2.2 GHz 28 205W 4800 MT/s 128 GB
Gold 5515+Processor 3.2 GHz 8 165W 4800 MT/s 128 GB





5th Generation Intel® Xeon® Scalable Processor Family (Silver)

 Intel® Xeon® Models Frequency Cores Power DDR5 SGX Enclave size
Silver 4516+ Processor 2.2 GHz 24 185W 4400 MT/s 64 GB
Silver 4514Y Processor 2.0 GHz 16 150W 4400 MT/s 64 GB
Silver 4510 Processor 2.4 GHz 12 150W 4400 MT/s 64 GB
Silver 4509Y Processor 2.6 GHz 8 125W 4400 MT/s 64 GB



5th Generation Intel® Xeon® Scalable Processor Family (Bronze)

 Intel® Xeon® Models Frequency Cores Power DDR5 SGX Enclave size
Bronze 3508U Processor1  2.1 GHz 8 125W 4400 MT/s 64 GB
